Tech Licensing

A new novel anchoring system has been designed for repeated anchoring of AUVs to the seabed, conserving power, reducing costs, and extending mission duration.

Summary

Users of Autonomous Underwater Vehicles (AUVs) often face limitations when operating vehicles in the field, with detrimental effects on mission planning, power consumption, scalability, vehicle safety, cost, and more. A new technological development has been created which enhances these capabilities and mitigates risks around deployment.

Background

Without the ability to anchor an AUV to the seabed, the scope and success of deployment can often depend upon favourable weather conditions. This – coupled with a dependency on battery power – creates substantial limitations on effective planning and execution. The lack of an innovative, risk-free anchoring solution for AUVs also increases the chance of an AUV being trapped on the seabed, with significant losses of cost and data collection at stake, as well as environmental pollution.

It was essential for seabed anchoring to be enabled and designed in a way for AUVs to mitigate these issues.

The solution

Developed by the National Oceanography Centre (NOC), the Anchor System represents a significant milestone in underwater technology and research. This innovation allows for multiple anchoring events of the same vessel – a solution for long-duration research and survey missions requiring underwater vehicles.

Repeated anchoring to the seafloor enables these vehicles to hibernate between work intervals and during unfavourable weather conditions. This technology can also lead to cost reduction by extending on-site mission durations and conserving battery power, as well as lowering the risk of an AUV and its collected data going missing.

How it works: the anchor compartment of the AUV is flooded, making the vessel negatively buoyant so that it sinks. Once the anchor hits the seabed, the AUV returns to positive buoyancy and rides clear, operating in low power mode to either hibernate or carry out passive monitoring as required. Once the AUV is due to continue its mission, the anchor tether is released.

Key Benefits

• This technology unlocks optimised mission planning, allowing the user to schedule launches and hibernation periods for underwater vehicles, ensuring they are primed and ready in ideal conditions – making operations more efficient and less weather-dependent.

• Minimal power consumption is required.

• The system can be retrofitted to existing underwater vehicles, maximising capability without a full overhaul.

• The system is scalable and can be made to fit a wide variety of vessel sizes.

• Enhanced vehicle safety – minimising the risk of vehicle loss during missions.

• Its low-cost, simple, straightforward design ensures reliability and ease of use.

Potential applications

The Anchor System has a wide range of useful applications, including but not limited to: oceanographic research, environmental monitoring and surveying, offshore energy exploration, pipeline inspection, and underwater archaeology. This is applicable to both optimising operational capacity in active missions, where it would be beneficial to have the ability to anchor to the seabed for battery saving between tasks, and for static missions, where the AUV stays in one set location and monitors its immediate environment (such as listening to marine life). An anchored AUV is virtually silent compared with the acoustic noise from operating thrusters, and therefore mitigates disturbance and disruptions around it, leading to more accurate readings.

Interested in discussing this technology further?

This technology is now available to license through our partner, Ploughshare. Contact us to find out more about this technology and discuss the licensing opportunities available.

Our radar imaging capabilities provide greatly enhanced and accurate situational awareness for vessels

Summary

NOC Innovations, in collaboration with Ploughshare Innovations, is introducing a groundbreaking radar imaging technology – High-Resolution Radar Image Mosaicking. This technique leverages commercial-off-the-shelf (COTS) radar systems and a unique ‘patch testing’ method for a radar installation to produce stabilised imagery for marine remote sensing, particularly effective in coastal and inshore waters. This advancement promises a phase-change in radar remote sensing capabilities, with potential applications in various sectors.

Background

There is currently a crucial gap in marine radar capabilities, particularly when it comes to creating accurate depictions of landmass and surface objects with a small radar cross section such as ARGO floats, micro-scale submersibles, surface debris or person overboard. In addition, small vessels are not traditionally exploited for marine remote sensing due to large ‘standard’ radar equipment being unsuitable.

Solution

Developed by the National Oceanography Centre (NOC), the High-Resolution Radar Image Mosaicking technique integrates with existing radar equipment, offers accurate depictions of landmass and surface objects over time from a moving vessel. This technology represents a significant departure from traditional radar imaging methods, catering specifically to small work class vessels and uncrewed surface vessels (USVs), thus expanding the horizon of radar remote sensing to new low-cost, low-power COTS radar hardware.

Key Benefits

• Unique ‘patch testing’ algorithms to enable precise geo-registration of radar imagery from any vessel-based radar installation


• Unlocks new additional situational awareness capability within existing COTS radar systems, including enhanced topographical imaging of landmass/surface objects.

• Fast data acquisition and processing, capable of generating high-resolution SAR-type imagery from radar in real time


• Mosaics into accurate depictions of landmass and surface objects


• Scalability across vessel sizes, particularly suitable for small vessels and USVs

• Seamless integration with most existing radar equipment

Potential Uses

This technology has a wide range of applications including commercial radar system operators, manufacturers and developers, with additional interest from end users across various sectors including defence and scientific research.

Interested in discussing this technology further?

This technology is now available to license through our partner, Ploughshare. Contact us via techtransfer@noc.ac.uk to find out more about this technology and discuss the licensing opportunities available.

A new water level monitoring technology provides users with a low-cost way to collect data from remote or challenging environments.

Traditional tide gauges face challenges in cost, installation and maintenance, which reduces their reliability and accessibility. A new technology, GNSS-IR, offers a novel approach to water level monitoring, facilitating near real-time measurements that are crucial for understanding coastal environments, waterway safety, and our natural resources, which overcomes these key issues for users.

Background

Water level monitoring is essential to a wide range of industries and organisations involved in understanding our coastal environments, inland waterways, and the management of natural resources. This can include: the safe navigation of ships, cargo vessels, and boats into and out of ports, coastal zone engineering projects and infrastructures, ecological, industrial, and environmental impact, and preparing for emergencies such as rising sea levels, coastal erosion, flooding, and more.

However, traditional tide gauges and wave buoys have been expensive to install and maintain, limiting their usage and meaning sparse data is only available to a narrow set of end users. Traditional options were also installed directly in the water, making them susceptible to damage or fouling from the harsh marine environment and passing vessels. This often resulted in the gauges being out of action for periods of time or a degradation in the measurements.

It was vital that an alternative, modern method that could complement existing systems of obtaining the necessary data was created. This would meet the need of circumventing these issues to better support the safety requirements and economic implications of maintaining safe waterways.

The solution

Created by the National Oceanography Centre (NOC), a new monitoring technology overcomes the challenges users previously faced to measure water levels and significant wave heights in near-real-time.

This technology utilises shore-mounted GNSS receivers and NOC’s own GNSS-IR software, removing the need for tide or water-level gauge hardware to be placed directly in the water. This greatly reduces the susceptibility to damage and bio-fouling compared to traditional tide gauges by installing it away from passing vessels and the harsh marine environment.

The technology is also easy to install and low-cost, enabling more gauges to be placed in a higher number of locations – increasing the data quality and quantity produced. It also extends monitoring capabilities to hard-to-reach areas, improving accessibility to water level data for users, both inland and coastal.

Key Benefits

• This technology can be used as an alternative to traditional tide gauges and wave buoys in water level and wave height data collection.
• It is low-cost, utilising Commercial Off-The-Shelf (COTS) hardware.
• It is capable of near-real-time water level and significant wave height measurements.
• The elevated, on-shore installation position minimises effects of fouling and damage by water vessels.
• Easy installation opens up opportunities in remote locations or challenging environments where traditional tide gauges are not feasible.
• Alternatively, this technology can also be used alongside traditional tide gauges to enhance capability by providing cost-effective, continuous levelling information, required for maintenance.

Potential Applications

Ports
This technology can help with monitoring tide measurements and significant wave heights to maintain safe shipping channels and aid operational management.

Inland waterways
This software enables the monitoring of local water level changes in near-real-time to inform actions for community safety and property protection.

Offshore renewables
Near real-time monitoring of wave conditions can improve personnel safety and inform the best access times to turbines for example.

Lifeboat stations
Affordable localised tide data can aid critical life-saving decisions.

Insurance providers
Providers can benefit from utilising near real-time water level and wave height data for quick verification of claims and customer assistance.

Interested in discussing this technology further?

This technology is now available to license through our partner, Ploughshare. Contact us via techtransfer@noc.ac.uk to find out more about this technology and discuss the licensing opportunities available.
